EN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun Group

EN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun Group

EN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun Group
EN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun GroupEN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun GroupEN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun GroupEN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun GroupEN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun GroupEN10210 S460NH LSAW Steel Hollow Section Supplier -Yuantai Derun Group
CategoriesLSAW steel pipe
BrandYuantai Derun Steel Pipe Manufacturing Group
ModelHollow Section
Outer Diameter355.6mm - 1440mm
Thickness6mm- 50mm
CertificationCE,EN,ISO,API
Toleranceas requirement
Secondary Or NotNon-secondary
Surface TreatmentBlack ,Yellow Varnish coating
EndsPlain,Bevelled
Delivery time7-30 days
Supply capacityAnnual output of 5 million tons
FOB portTianjin port
Terms of PaymentL/C, T/T
Download
Update TimeDec 2,2024
Detail Information

EN10210 S460NH LSAW Hollow Section Supplier -Yuantai Derun Group

EN 10210 S460NH LSAW hollow section is also known as low-carbon steel pipe. EN10210 S460NH LSAW Hollow Section is a widely used steel hollow section. It has the advantages of structural stability, excellent performance, strong bearing capacity, and affordability. The carbon content of EN 10210 S460NH LSAW Hollow Section is up to 0.2%, and the manganese content ranges from 1.00% to 1.70%, making them easy to form. These hollow sections are manufactured according to EN10210 standards and are commercially referred to as CS pipes or MS pipes.

EN 10210-1 Grade S460NH Hollow Section Properties

Chemical Composition

C
Si
Mn
P
S
Ni
Cr
≤0.22%
≤0.60%
1.00-1.70%
≤0.035%
≤0.025%
≤0.8%
≤0.3%
Mo
Cu
Nb
V
Ti
Al
N
≤0.2%
≤0.55%
≤0.05%
≤0.2%
≤0.05%
≥0.02%
≤0.025%

Physical And Mechanical Strength

Tensile Strength
Yield Strength
Elongation Rate
W.T. ≤16mm
W.T. > 16 mm
W.T. ≤ 40 mm
W.T. > 40mm
W.T. ≤ 65mm
540–720 MPa
≥460 MPa
≥440 MPa
≥ 430 MPa
≥15%

EN 10210 S460NH Steel Grade Is Equivalent To Steel Grades In Other Countries

GB
DIN
BS
NFA
EN
ASTM
Q460
DIN (17123/24/25) Grade FGS 47
NFA A 36-2011) Grade E 460 R+FP
ASTM A 678 Grade C
EN 10210-1 Grade S460NH
ASME SA 678 Grade C

Dimensions And Sectional Properties Of A Limited Range Of Circular Hollow Sections

Advantage

The LSAW hollow section produced by Yuantai Derun has the following advantages.
1. China lsaw steel tube brand leader
2. Ce certification lsaw steel tube
3. CNAS certification china lsaw steel tube factory
4. LEED certification china lsaw steel tube manufacturer
5. BV certification china lsaw steel tube supplier
6. ABS certification EN 10210-1 Grade S460NH Carbon Steel Pipe brand

One Corner Of Workshop

EN10210 S460NH LSAW Hollow Section
Smooth pipe end
EN10210 S460NH LSAW Circular Hollow Section
Chamfered edge
EN10210 S460NH LSAW Hollow Section
Sizing
Forming

Strict Layer By Layer Inspection For You

Impact Test
Impact Test
Yield Test & Tensile Test
Yield Test & Tensile Test
Chemical Composition Test
Chemical Composition Test

Certificate

PhD
BC1
ISO14001
ISO9001
EN10210
BV
EPD
JIS G3466

Application And Case

EN10210 S460NH LSAW hollow section is used for many industries.The EN10210 S460NH LSAW hollow section produced by Yuantai Derun has also been applied to major projects at home and abroad multiple times.
Qatar Airport
Qatar Airport
500 Tons EN10210 S460NH LSAW hollow section produced by Yuantai Derun was used in Qatar Airport.
Qiddaya speed park project- the blade
Qiddaya speed park project- the blade
11000 Tons EN10210 S460NH LSAW hollow section produced by Yuantai Derun was used in Qiddaya speed park project
